Positioneersystemen
Of u nu kiest voor geleidingen van Unimotion, een kant en klaar positioneersystemen van Systec of voor de modules van Jung, in combinatie met LinMot ? Wij helpen u bij het bepalen van de juiste keuze.
Subcategorieën
Tandriem aangedreven lineaire geleidingen
![Tandriemaandrijving type MTJ ECO Tandriemaandrijving type MTJ ECO](https://groneman.nl/wp-content/uploads/2021/01/Serie-MTJ-eco-300x180.png)
- Compacte afmeting
- Ook voor verticale bewegingen
- Rijsnelheid: tot 10 m/s
- Max. slag: Tot 5968 mm
Kogelomloop aangedreven lineaire geleidingen
![BSD-MTV BSD-MTV](https://groneman.nl/wp-content/uploads/2023/06/BSD-MTV-300x180.png)
- Compacte afmeting
- Hoge belastbaarheid
- Hoge snelheid
- Hoge nauwkeurigheid
Servo aangedreven lineaire geleidingen
![DM01-37 Lineaire geleiding met hogere buigstijfheid DM01-37 Lineaire geleiding met hogere buigstijfheid](https://groneman.nl/wp-content/uploads/2021/05/DM01-37-300x185.jpg)
- Compacte geleidingseenheden voor lineaire motoren
- Voor opname externe krachten
- Dynamisch en nauwkeurig positioneren
Producten
Motor met geïntegreerde geleiding P04
![](https://groneman.nl/wp-content/uploads/2020/08/P04_IP65.png)
- Piekkracht tot 572 N
- Slaglengte tot 150 mm
- Geharde precisie-as
- Montage aansluiting volgens ISO-pneumatische cilinder
Lineaire modules DM01
![](https://groneman.nl/wp-content/uploads/2020/12/3-e1689778583164.jpg)
- Directe montage van de belasting met absorptie van dwarskrachten
- Geanodiseerde aluminium behuizing
- Corrosiebestendige, hard verchroomde geleidingsstangen
Lineaire modules FM01/EM01
![](https://groneman.nl/wp-content/uploads/2021/11/5-LinMot-F-Guides-F01-48-small.jpg)
- Compacte, hoogdynamische module voor toepassingen met lange slag en meerassige configuraties
- Module met hoog draagvermogen voor toepassingen waar stabiliteit en ondersteuning van momentbelasting van belang zijn
Lineaire module SM01
![](https://groneman.nl/wp-content/uploads/2020/12/SM01-48x150G-HP-C-255_SSCP-e1707316944293.png)
- Hoge weerstand tegen chemicaliën
- Geschikt voor “wash-down” met beschermingsklasse IP69
- Optimaal ontworpen voor “in-place” reinigingsprocessen zoals CIP en SIP.
Lineaire module SM02
![](https://groneman.nl/wp-content/uploads/2024/02/SM02-37Sx120F-HP-310_BE03_SSCP-e1707316975136.png)
- Hoge weerstand tegen chemicaliën
- Geschikt voor “wash-down” met beschermingsklasse IP69
- Optimaal ontworpen voor “in-place” reinigingsprocessen zoals CIP en SIP.
Lineaire H-geleidingen
![](https://groneman.nl/wp-content/uploads/2020/08/Lineaire-geleidingen_H_groep.jpg)
- Opname van externe krachten, koppels en buigmomenten
- Anti rotatie ondersteuning
- Compatibel met pneumatische geleidingen
Lineaire B-geleidingen
![](https://groneman.nl/wp-content/uploads/2020/08/Lineaire-B-geleidingen.png)
- Verhoogde stijfheid door eindplaat
- Gebruik met ondermaatse lopers
- Ondersteunt externe krachten, koppels, en buigmomenten
Grijper module GM01
![](https://groneman.nl/wp-content/uploads/2024/02/gm01-grijper-module.png)
- Roestvast staal EN 1.4404
- Geschikt voor “wash-down” met beschermingsklassen tot IP69
- Lichtgewicht materialen (FDA)
- 100% procesbewaking en traceerbaarheid
HighDynamic
![](https://groneman.nl/wp-content/uploads/2020/08/HighDynamic.png)
- Piekkracht tot 1.024 N
- Slaglengtes mogelijk tot 330 mm
- Ideaal voor korte slaglengtes
FourDynamic
![](https://groneman.nl/wp-content/uploads/2020/08/FourDynamicWEB.jpg)
- Piekkrachten tot 2.500 N
- Slaglengtes mogelijk tot 350 mm
- Ideaal voor korte slaglengtes
- Voor 400V techniek
QuickAx
![](https://groneman.nl/wp-content/uploads/2020/08/QUickAx.png)
- Slaglengtes mogelijk tot 120 mm
- Ultravlakke en draaistijve constructie
- Piekkrachten tot 67 N
- Herhaalnauwkeurigheid +/- 0,001 mm
ParaPicker Pick&Place
![](https://groneman.nl/wp-content/uploads/2021/01/parapicker-pickPlace.png)
- Pick&Place met parallelle kinematica
- Hoogste dynamiek d.m.v. lineaire directe aandrijvingen
- Vrij positioneerbaar in het gehele werkgebied
- Ook geschikt voor ruwe omgevingen
Parapicker Robot
![](https://groneman.nl/wp-content/uploads/2020/08/Parapicker-robots.png)
- De dynamiek
- De kracht in de Z-as
- Kleine reactiekrachten en geringe vibratie
Tandriemaandrijving type CTJ
![](https://groneman.nl/wp-content/uploads/2021/01/Serie-CTJ.png)
- Compacte afmeting
- Ook voor verticale bewegingen
- Hoge snelheid
- In de bouwgroottes 90, 110, 145, 200
Tandriemaandrijving type MTJ
![](https://groneman.nl/wp-content/uploads/2021/01/Serie-MTJ.png)
- Compacte afmeting
- Ook voor verticale bewegingen
- Hoge snelheid
- In de bouwgroottes 40, 65, 80, 110
Tandriemaandrijving type MTJ ECO
![](https://groneman.nl/wp-content/uploads/2021/01/Serie-MTJ-eco.png)
- Compact
- Sterk
- Gunstig geprijsd
Tandriemaandrijving type MRJ
![](https://groneman.nl/wp-content/uploads/2021/01/Serie-MRJ.png)
- Compacte afmeting
- Ook voor verticale bewegingen
- Hoge snelheid
- In de bouwgroottes 40, 65, 80, 110
Tandriemaandrijving type MTJZ
![](https://groneman.nl/wp-content/uploads/2020/08/Serie-MTJZ.png)
- Compacte afmeting
- Ook voor verticale bewegingen
- Hoge snelheid
- In de bouwgroottes 40, 65, 80, 110
Tandriemaandrijving type MGTB
![](https://groneman.nl/wp-content/uploads/2023/06/MGTB45_VK_MOT.png)
- Hoge snelheid
- Goede positioneernauwkeurigheid
- Hoge herhaalbaarheid
Kogelomloopspindelaandrijving type CTV
![](https://groneman.nl/wp-content/uploads/2023/06/BSD-CTV.png)
- In de bouwgroottes 90, 110, 145, 200
- Snelheid tot 2,5 m/s
- Maximale slag tot 2.000 mm
- Maximale axiale belasting tot 29.600 N
- Maximaal aandrijfkoppel tot 52,3 Nm
Kogelomloopspindelaandrijving type MTV
![](https://groneman.nl/wp-content/uploads/2023/06/BSD-MTV.png)
- In de bouwgroottes 40, 65, 80, 110
- Snelheid tot 2,5 m/s
- Maximale slag tot 5.456 mm
- Maximale axiale belasting tot 29.600 N
- Maximaal aandrijfkoppel tot 52,3 Nm
Kogelomloopspindelaandrijving type MGBS
![](https://groneman.nl/wp-content/uploads/2023/06/BSD-MGBS.png)
- In de bouwgroottes 32, 45, 60
- Snelheid tot 0,97 m/s
- Maximale slag tot 1.000 mm
- Maximale axiale belasting tot 1.100 N
- Optioneel met plug and drive stappenmotor
Lineaire unit type CTL
![](https://groneman.nl/wp-content/uploads/2023/04/Hypex_Stills_CTL_05_bew.png)
- In de bouwgroottes 145, 200, 250
- Snelheid tot 5,0 m/s
- Maximale slag tot 5.970 mm
- Maximale axiale belasting tot 2.470 N
- Continue kracht tot 1.125 N
- Piekkracht tot 2.475 N\
Meerassige systemen
![](https://groneman.nl/wp-content/uploads/2023/06/multi-axis.png)
- combinatie verschillende meerassige lineaire systemen mogelijk
- flexibele combinatie van diverse accessoires
DriveSet M-serie
![](https://groneman.nl/wp-content/uploads/2020/08/Typische-Kinematiken-von-DriveSets.png)
- Inbouwklaar positioneersysteem
- lineaire beweging met 1, 2 of 3 assen
DriveSet MR-serie
![](https://groneman.nl/wp-content/uploads/2020/08/rotationsmodule.png)
- Een-assig systeem met rotatiemodule
Accessoires Unimotion
![](https://groneman.nl/wp-content/uploads/2020/08/accessoires.png)
